MATSUURA MAM72-52V - 5-AXIS VERTICAL | Machining Center

SPINDLE
15,000 RPM HIGH-SPEED CAT #40 GREASE LUBRICATED SPINDLE WITH COVER
INCLUDES 2 YEAR WARRANTY ON ALL SPINDLE COMPONENTS

TOOLS
330 TOOL MATRIX

PALLET CHANGER
15 PALLET SYSTEM WITH INCH PALLETS

GENERAL
SCALE FEEDBACK FOR (X,Y,Z) AXIS/ HEIDENHAIN SCALE
HEIDENHAIN LINEAR GLASS SCALE FEEDBACK - B & C AXIS ARE STANDARD WITH ROTARY SCALES

(8) EXTRA M-FUNCTIONS
FOR 3RD PARTY ACCESSORY INTEGRATION

3-COLOR PRODUCTION MONITORING LIGHT
RED/GREEN/YELLOW

WEEKLY TIMER
7-DAY AUTOMATIC POWER-UP AND AUTOMATIC POWER-DOWN FUNCTION

AIR BLOW FOR CHIP SWARF REMOVAL

AIR DRIVEN ROTARY WIPER

MOVEABLE MANUAL PULSE GENERATOR

WORKPIECE CLEANING GUN ON MACHINE & APC SIDES

PROBING OPTIONS
SPINDLE PROBE –OMP-400 WITH CALIBRATION MASTER

LASER TOOL SETTER – RENISHAW NC4 BLUE

SOFTWARE
SPINDLE LOAD MONITORING FUNCTION
ALLOWS AN OPERATOR TO TEACH REFERENCE TORQUE VALUES FOR THE FEED AND SPINDLE AXIS FOR A NEW TOOL. WHEN A TOOL REACHES A WARNING LEVEL THE OPERATOR IS NOTIFIED. IF THE TORQUE VALUES REACH ANOTHER LIMIT THE MACHINE IS HALTED.

TOOL PRE-CHECK OPTION
THE CONTROL DETERMINES A LIST OF REQUIRED TOOLS FOR THE NEXT PALLET PROGRAM AND ENSURES THAT THE CORRECT TOOLS ARE AVAILABLE BEFORE BEGINNING TO CUT.

EZ-5 V2 W/ CALIBRATION BALL

EZ-5 V2 SCHEDULING SUPPORT FUNCTION

3D MODEL OF WORK ENVELOPE IN STL/IGES/STEP FORMAT

OPERATION STATUS MONITORING FUNCTION

SYNCHRO TIP + ORBITAL MACHINING FUNCTION

CYLINDRICAL INTERPOLATION

READER PUNCH INTERFACE (1CH)

COOLANT
MATSUURA FP-70 1,000 PSI THROUGH SPINDLE COOLANT SYSTEM
INCLUDES COOLANT PUMP, VACUUM, VACUUM SOLENOID, AND COOLANT CHILLER

COOLANT SHOWER SYSTEM
FOR MACHINING AREA WASH-DOWN WHILE CUTTING

COOLANT FLOW CHECKER WITH SPINDLE THROUGH

PREPARATION FOR MIST COLLECTOR

FANUC PACKAGES
MMU VALUE PACKAGE
o TOOL OFFSET PAIRS 999-PAIRS
o ADDITION OF WORKPIECE COORDINATE SYSTEM 300-PAIRS
o OPTIONAL BLOCK SKIP 9
o QUICK PROGRAM RESTART
o COORDINATE SYSTEM ROTATION
o TOOL LIFE MANAGEMENT
o PART PROGRAM STORAGE SIZE 8 MEGABYTES
o HIGH-SPEED SKIP
o COMMON VARIABLE EXPANSION (#100-#199/ #500-#999)

HIGH SPEED/ HIGH PRECISION PACKAGE + 5 AXIS PACKAGE
o IZ-2/150NF
o SMOOTH TOLERANCE CONTROL
o HIGH SPEED SMOOTH TCP
o OPTIMAL TORQUE ACCELERATION & DECELERATION
o DATA SERVER PACKAGE WITH ETHERNET CONNECTIVITY AND 4 GIGABYTE OF PROGRAM STORAGE
o LARGE CAPACITY MEMORY (16 GB SSD)
o TILTED WORK PLANE COMMAND
o 3-DIMENSIONAL COORDINATE SYSTEM CONVERSION
o 3-DIMENSIONAL MANUAL FEED
o MANUAL INTERRUPTION OF 3-DIMENSIONALCOORDINATE
o RETRACTION OF 3-DIMENSIONAL RIGID TAPPING
o 3-DIMENSIONAL ROTARY ERROR COMPENSATION
o 3-DIMENSIONAL CUTTER COMPENSATION
o WORK SET-UP ERROR COMPENSATION
o INVERSE TIME FEED
